Product name：Trailer Pump
Belonging classification：Concrete equipment
Whatsapp：+8615890058390
Mailbox：sales@superequipment.cn
Trailer Pump details
Technical parameters
Model | SBTS40 | SBTS50 | SBTS60 | SBTS80 |
Theoretical displacement (m3/h) | 37/24 | 51/32 | 80/50 | 80/50 |
Pressure (Mpa) | 10/6 | 12/7 | 13/7.5 | 16/9 |
Maximum conveying distance, vertical/horizontal (m) | 500/150 | 600/160 | 1000/150 | 1000/150 |
power (KW) | 45 | 75 | 90 | 110 |
Main oil pump displacement | 112 | 140 | 112X2 | 140X2 |
Conveyor cylinder bore X stroke (mm) | 160X1000 | 180X1100 | 200X1650 | 200X1650 |
Oil injection cylinder bore X stroke (mm) | 100X1000 | 110X1300 | 125X1650 | 140X1650 |
High and low voltage switching | YES | YES | YES | YES |
Hopper volume (m3) | 0.4 | 0.4 | 0.6 | 0.6 |
Maximum aggregate particle size (mm) | 40/30/25 | 40/30 | 50/40 | 50/40 |
Outlet inner diameter (mm) | 140 | 150 | 180 | 180 |
(mm) | 1250 | 1300 | 1450 | 1500 |
Dimensions LX W X H (mm) | 4200X1520X1750 | 4800X1520X1750 | 5900X2000X2260 | 6200X2000X2260 |
Weight(kg) | 3500 | 4000 | 6000 | 6300 |
Technical parameters
●The oil pump adopts the variable plunger pump of famous brand with high rated pressure; the valve group adopts American Eaton or Beijing Huade, the quality is stable and reliable.
●The whole series adopts electronically controlled hydraulic system, the system is simple and clear, and the maintenance is convenient.
●Hydraulic system adopts electric control system which is mature and concise, with low failure rate and convenient maintenance. The oil pump and valve parts are all used well-known brands, and the quality is stable and reliable.
●Air-cooled and water-cooled dual cooling systems ensure the equipment can work normally even in extremely hot weather (temperature above 40℃).
●Unique design of reversing buffer
●Centralized lubrication system adopts multi-point direct oil supply method, which has high oil supply pressure and efficiency.
